M177 NRF24L01+ 2.4GHz Antenna Wireless Transceiver Module – High-Speed, Low-Power RF Communication for IoT & Robotics
The M177 NRF24L01+ 2.4GHz Antenna Wireless Transceiver Module is a compact and ultra-efficient RF module designed for reliable wireless communication in the 2.4GHz ISM band. It delivers high performance with low power consumption, making it ideal for IoT devices, robotics, and remote sensor networks.
Built around Nordic’s advanced NRF24L01+ chipset, this module supports both transmit and receive operations, enabling point-to-point or multi-node communication. It’s widely compatible with Arduino, Raspberry Pi, ARM, Mbed, and other popular microcontrollers — providing easy integration for developers and makers.
Key Features
- High-Speed Wireless Data: Supports up to 2 Mbps transfer rate with GFSK modulation for stable, interference-free communication.
- Ultra Low Power Design: Consumes less than 1 µA in power-down mode and under 14 mA during transmission/reception.
- Optimized for Battery Operation: Ideal for coin cell, AA, or AAA-powered systems with extended battery life.
- Wide Compatibility: Works seamlessly with Arduino, Raspberry Pi, ARM, and Mbed controllers.
- Integrated 2.4GHz Antenna: Ensures strong, stable wireless communication without external components.
- 125 Communication Channels: Supports frequency hopping and multi-point networking for robust communication.
- Built-in CRC & Address Control: Provides error-free, secure, and stable data transmission.
- Easy Integration: DIP pin spacing and onboard voltage regulation simplify prototyping and circuit design.
🔧 Technical Specifications
| Operating Frequency | 2.4GHz ISM Band |
| Modulation Type | GFSK |
| Data Rate | 250 kbps / 1 Mbps / 2 Mbps |
| Operating Voltage | 1.9V – 3.6V (3.3V recommended) |
| Current Consumption | <14mA (TX/RX), <1µA (Power Down) |
| Number of Channels | 125 |
| Communication Range | Up to 100 meters (open area) |
| Interface | SPI (Serial Peripheral Interface) |
| Antenna Type | Built-in 2.4GHz PCB Antenna |
| Power Supply | 3.3V DC |
| Dimensions | Approx. 29mm × 15mm |
Highlights
- Ideal for IoT, robotics, and wireless control systems.
- Supports multi-node communication and frequency hopping for robust connections.
- Fully compatible with Arduino RF24 and Mirf libraries.
- Ultra-low power consumption ensures long battery life in portable devices.
- Simple SPI interface for plug-and-play integration with microcontrollers.
Applications
- Smart Home & IoT Devices
- Robotics and Remote-Controlled Systems
- Wireless Sensor Networks
- Industrial Automation & Monitoring
- Data Transmission & Telemetry Projects
Package Includes
- 1 × M177 NRF24L01+ 2.4GHz Antenna Wireless Transceiver Module
Experience reliable, high-speed wireless communication with the NRF24L01+ — the trusted choice for IoT, robotics, and embedded projects.
